162 Upgrade and Maintenance Manual RX2540 M4
Hard disk drives (HDD) and solid state drives (SSD)
7.3.9.3 Connecting the SAS cables (two 3.5-inch HDD backplanes)
Cabling with onboard SATA
Figure 71: Connecting the second 3.5-inch HDD backplane to the system board
Ê Connect the cable of the second HDD backplane to the system board
connector "SATA 4-7" (1).
