RX2540 M4 Upgrade and Maintenance Manual 297
Expansion cards and backup units
9.10.2 Removing a GPGPU card from riser module 1
9.10.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê If applicable, remove all external cables from the expansion card to be
removed.
I If there is a cable installed to an expansion card in the upper slot, see
section "Note for installation with expansion cards in slot 5 and slot
11" on page 71.
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, disconnect internal cables from the GPGPU card.
9.10.2.2 Removing the air duct
Ê Remove the air duct, see section "Removing the air duct" on page 88.
9.10.2.3 Removing the FBU
Ê Remove the FBU, see section "Removing an FBU from the riser card holder
(FL)" on page 322.
9.10.2.4 Removing the riser module 1
Ê Remove the riser module 1, see section "Removing the riser module 1 (FL)"
on page 82.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
