Hard disk drives (HDD) and solid state drives (SSD)
I The PCIe SSDs are mounted in the same frames as the 2.5-inch
HDD/SSD modules.
7.4.12.6 Concluding steps
Ê "Installing the fan holder" on page 234
Ê "Reassembling" on page 63
Ê "Installing 2.5-inch HDD/SSD modules" on page 182
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Ê "Resuming BitLocker functionality" on page 112
7.5 Rear HDD/SSD or PCIe SSD extension box
7.5.1 Replacing the backplane of the extension box
7.5.1.1 Preliminary steps
Ê "Locating the defective server" on page 53
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê Remove all HDD/SSD modules from the server, see section "Removing 2.5-
inch HDD/SSD modules" on page 185.
V CAUTION!
Ensure that all HDDs are uniquely identified so that you can reinsert
them into their original bays after replacing the HDD backplane.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
