RX2540 M4 Upgrade and Maintenance Manual 435
Ê Fasten the air grid with 4 screws.
Ê "Installing the front panel cage" on page 445
13.5.2.3 Concluding steps
Ê "Installing the fan holder" on page 234
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Resuming BitLocker functionality" on page 112
13.5.3 Replacing a RDX drive
13.5.3.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
Ê "Removing the front panel cage" on page 439
13.5.3.2 Removing the defective RDX drive
Ê "Removing the RDX drive" on page 432
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
