RX2540 M4 Upgrade and Maintenance Manual 341
10.3 Removing a memory module
10.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, remove the riser module, see section "Riser modules for
GPGPU cards (FL)" on page 82.
10.3.2 Removing a memory module
Figure 225: Removing memory modules (A)
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory slot.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for the riser module)
