RX2540 M4 Upgrade and Maintenance Manual 339
10.2 Installing a memory module
10.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, remove the riser module, see section "Riser modules for
GPGPU cards (FL)" on page 82.
10.2.2 Selecting the memory slot
Ê Choose the memory slot according to the configuration rules in "Basic
information" on page 328.
10.2.3 Installing a memory module
Figure 223: Opening the securing clips
Ê Press the securing clips on both sides of the memory slot concerned
outward.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for the riser module)
