Fujitsu PRIMERGY RX2540 M4 Upgrade And Maintenance Manual

3RX2540 M4
List of used cables
Cable plan
Ref Partnumber Naming
C1 T26139-Y4015-V301 CBL FRONT PANEL GTL
C2 T26139-Y3999-V508 CBL_USB30_580
C3 T26139-Y4028-V304 CBL SATA 850
C4 T26139-Y3994-V301 CBL_FRONT_VGA
C5 T26139-Y4042-V6 CBL FLEXP 22PL 560
C6 T26139-Y3589-V410 CBL SERIAL 150
C7 T26139-Y4015-V605 CBL_SMB_4XBP
C8 T26139-Y3994-V303 CBL_REAR_VGA
C9 T26139-Y3939-V503 CBL PWR SAS-BP 660
C10 T26139-Y3939-V502 CBL RX2520M1 PWR35
C11 T26139-Y3939-V206 CBL_PWR_6P_4P_200 GTL
C12 T26139-Y3939-V210 CBL_PWR_6P_4P_500
C13 T26139-Y3959-V353 CBL_PWR_ EXP_150 GTL
C14 T26139-Y4031-V102 CBL_FBU30_320
C15 T26139-Y4031-V107 CBL_TFM_EP540_550
C16 T26139-Y3986-V302 CBL PWR 2CO 400
C17 T26139-Y3986-V306 CBL PWR 3CO 600
C18 T26139-Y2193-V501 CBL PWR RDX 400
C19 T26139-Y3946-V705 CBL GPU PWR 320 GTL
C20 T26139-Y3946-V706 CBL_PWR_GPU_3_RAIL
C40 T26139-Y3946-V703 CBL_GPU_BP_830
C21 T26139-Y4040-V38 CBL SAS3.0 500
C22 T26139-Y4040-V25 CBL SAS3.0A720
C23 T26139-Y4040-V26 CBL SAS3.0A500
C24 T26139-Y4040-V8 CBL HOST-BP 470
C25 T26139-Y4040-V9 CBL HOST-BP 540
C26 T26139-Y4040-V10 CBL HOST-BP 620
C27 T26139-Y4040-V58 CBL SAS3.0 580
C28 T26139-Y4040-V59 CBL SAS3.0 610
C29 T26139-Y4040-V39 CBL_SAS3.0_220 AST
C30 T26139-Y4040-V30 CBL_SAS30_RAL_150
C31 T26139-Y4040-V31 CBL_SAS30_RAL_180
C32 T26139-Y4040-V32 CBL_SAS30_RAL_210
C33 T26139-Y4040-V33 CBL_SAS30_250_RAL
C34 T26139-Y4040-V66 CBL_SAS30_700
C36 T26139-Y4044-V1 CBL_SAS_DEV_PR_DAL
C37 T26139-Y4039-A80 CBL USB3.0AN 0,8M
C38 T26139-Y4040-V60 CBL SAS3.0 580 ANG
C39 T26139-Y4040-V61 CBL SAS3.0 800 ANG
C41 T26139-Y2361-V103 CBL_HDD_SIG_200

Fujitsu PRIMERGY RX2540 M4 Specifications

General

Processor	Intel Xeon Scalable Processor Family
Form Factor	2U rack server
Chipset	Intel C621
Memory	Up to 3TB DDR4
Storage	Up to 24 x 2.5-inch SAS/SATA/NVMe drives or Up to 12 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60 (with optional controller)
Expansion Slots	Up to 8x PCIe Gen3 slots
Power Supply	800W or 1200W (1+1 redundant)
Memory Type	DDR4
Management	iRMC S5 (Integrated Remote Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
