324 Upgrade and Maintenance Manual RX2540 M4
Expansion cards and backup units
9.11.5.4 Removing the FBU from the holder
Figure 219: Removing the FBU from the holder
Ê Pull the FBU at a slight angle out of the holder.
9.11.5.5 Concluding steps
Ê If there is no FBU to install again, the FBU cable can be removed carefully.
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
