Expansion cards and backup units
9.1 Basic information
Figure 144: PCI slots (system board)
I For system relevant information, see the hardware configurator of your
server available online at the following address:
http://ts.fujitsu.com/products/standard_servers/index.htm
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy/
iRMC
S5
external connectors
TPM
LAN 1
Slot 3 (CPU1) Riser slot 1
SATA
0-3
Slot 1 (CPU1)
Slot 9 (CPU2) Riser slot 2
COM 1
SATA
4-7
SATA
ODD
Slot OCP module
Micro
SD
LAN M
USB3.0 1/2
LAN 2
M.2
SSD1
M.2
SSD2
HDD LED2
LAN 1/ M
Slot 8 (CPU2)
Slot 7 (CPU2)
Riser slot ext.
Slot 2 (CPU1)RAID
Riser slot ext.
Rear VGA
Intrusion
PWR4
HDD LED1
HDD LED7
VROC
