Fujitsu PRIMERGY RX2540 M4

RX2540 M4 Upgrade and Maintenance Manual 547
Appendix A
17.1.3 Server interior
Server with air cooling
Figure 412: PRIMERGY RX2540 M4 interior (example: 2.5-inch HDD model)
*
)
The OCP module is an option.
Pos. Component
1 Up to 2 PSUs / dummy cover
2 Front panel module / front VGA (option) / dummy cover
3 ODD (option) / dummy cover
4 Up to 24x 2.5-inch HDDs / dummy modules
5 Fan modules
6CPUs
7 Main memory
8PCI slots
9 OCP module *
10 PCIe SSD rear
