532 Upgrade and Maintenance Manual RX2540 M4
System board and components
16.6.2.3 Concluding steps
Ê "Installing the air duct" on page 89
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
16.6.3 Replacing the Dual microSD 64GB Enterprise
16.6.3.1 Preliminary steps
Ê "Locating the defective server" on page 53
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
16.6.3.2 Replacing the Dual microSD 64GB Enterprise
Ê Remove the defective Dual microSD 64GB Enterprise, see section
"Removing the Dual microSD 64GB Enterprise" on page 529.
Ê Remove both microSD cards from the defective Dual microSD 64GB
Enterprise. Proceed as described in the following:
Figure 401: Removing the microSD card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
