214 Upgrade and Maintenance Manual RX2540 M4
Hard disk drives (HDD) and solid state drives (SSD)
7.5.1.6 Connecting cables to the rear backplane
Ê Connect the corresponding cables to the backplane:
– The SAS cable, see figure 123 on page 210, 1.
– The color-coded Oculink cables (for the PCIe SSD backplane type 1),
see figure 124 on page 210, 1-4:
– The color-coded Oculink cables (for the PCIe SSD backplane type 2),
see figure 125 on page 211, 1-4:
– The power cable, see figure 123-2, or figure 124-5, or figure 125-5.
– If applicable, the OOB cable, see figure 123-3, or figure 124-6, or
figure 125-6.
Color Connector on PCIe SSD backplane
red "P0_X1"
yellow "P1_X2"
green "P2_X3"
black "P3_X4"
Color Connector on PCIe SSD backplane
red "P1_X1"
yellow "P2_X2"
green "P3_X3"
black "P4_X4"
