Appendix A
17.1.1.2 2.5-inch HDD versions
Figure 408: Front side 2.5-inch HDDs (up to 16 HDDs)
Figure 409: Front side 2.5-inch HDDs (up to 24 HDDs)
Pos. Component
1 Front panel module
2ODD
3 Space for LTO drive
4 Space for HDDs (depending on the configuration)
