454 Upgrade and Maintenance Manual RX2540 M4
14.3.3.3 Removing the front VGA board
Ê Remove the front VGA board, see section "Removing the front VGA board"
on page 452.
14.3.3.4 Installing the new front VGA board
Ê Install the new front VGA board, see section "Installing the front VGA board"
on page 450.
14.3.3.5 Installing the front panel module
Ê Install the front panel module, see section "Replacing the front panel
module" on page 438.
14.3.3.6 Concluding steps
Ê "Installing the fan holder" on page 234
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Ê "Resuming BitLocker functionality" on page 112
14.4 Front USB3.0 connector (2.5-inch version)
I The maximum external cable length is limited to 3 m.
14.4.1 Installing the front USB3.0 connector
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PZ2 screw driver / hexagon screw driver 5 mm
