280 Upgrade and Maintenance Manual RX2540 M4
Expansion cards and backup units
Ê Remove the rear air grid (see arrow).
V CAUTION!
Keep the rear air grid for future use.
Always replace rear air grids into unused installation locations to
comply with applicable EMC regulations and satisfy cooling
requirements.
9.9 Expansion cards in riser modules (HL)
I HL means cards with half length (about 130 mm).
9.9.1 Installing an expansion card in riser module 1
9.9.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, "Installing the riser card" on page 73
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver / hexagon screw driver 5 mm

Fujitsu PRIMERGY RX2540 M4 Specifications

General

Processor	Intel Xeon Scalable Processor Family
Form Factor	2U rack server
Chipset	Intel C621
Memory	Up to 3TB DDR4
Storage	Up to 24 x 2.5-inch SAS/SATA/NVMe drives or Up to 12 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60 (with optional controller)
Expansion Slots	Up to 8x PCIe Gen3 slots
Power Supply	800W or 1200W (1+1 redundant)
Memory Type	DDR4
Management	iRMC S5 (Integrated Remote Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
