RX2540 M4 Upgrade and Maintenance Manual 529
System board and components
Ê "Switching on the server" on page 70
16.6.2 Removing the Dual microSD 64GB Enterprise
16.6.2.1 Preliminary steps
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
16.6.2.2 Removing the Dual microSD 64GB Enterprise
Removing the Dual microSD 64GB Enterprise from the air duct
Figure 397: Removing the Dual microSD 64GB Enterprise from the air duct
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
