RX2540 M4 Upgrade and Maintenance Manual 459
14.4.3 Replacing the front USB3.0 connector
14.4.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Locating the defective server" on page 53
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
14.4.3.2 Removing the front panel module
Ê Remove the front panel module, see section "Replacing the front panel
module" on page 438.
14.4.3.3 Removing the front USB3.0 connector
Ê Remove the front USB3.0 connector, see section"Removing the front
USB3.0 connector" on page 458.
14.4.3.4 Installing the new front USB3.0 connector
Ê Install the new front USB3.0 connector, see section "Installing the front
USB3.0 connector" on page 454.
14.4.3.5 Installing the front panel module
Ê Install the front panel module, see section "Replacing the front panel
module" on page 438.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PZ2 screw driver / hexagon screw driver 5 mm
