Additional interfaces
15.1.3 Replacing the serial connector
15.1.3.1 Preliminary steps
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
15.1.3.2 Removing the serial connector
Ê "Removing the serial connector" on page 491
15.1.3.3 Installing the serial connector
Ê "Installing the serial connector" on page 488
15.1.3.4 Concluding steps
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: hexagon screw driver 5 mm
