284 Upgrade and Maintenance Manual RX2540 M4
Expansion cards and backup units
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Ê "Resuming BitLocker functionality" on page 112
9.9.3 Installing an expansion card in riser module 2
9.9.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, "Installing the riser card" on page 73
9.9.3.2 Installing an expansion card in a riser module 2
Ê Install the expansion card, see section "Installing an expansion card in a
riser module" on page 281.
9.9.3.3 Installing the air grid extension to the riser module 2
Ê Install the air grid extension to the riser module 2, see section "Installing the
air grid extension to riser module 2" on page 275.
9.9.3.4 Remove the slot cover for the riser module 2
Ê Remove the slot cover for the riser module 2, see section "Removing the slot
cover for the riser module 2" on page 272.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
