402 Upgrade and Maintenance Manual RX2540 M4
Accessible drives
Figure 282: Installing ODD latch to the front cage
Ê Turn the ODD latch 180
o
as shown (1).
Ê Fasten the ODD latch with two screws as shown (2).
13.2.2.3 Installing the ODD dummy cover
Figure 283: Installing the ODD dummy cover
Ê Install the ODD dummy cover.
