16.6 Dual microSD 64GB Enterprise
16.6.1 Installing the Dual microSD 64GB Enterprise
16.6.1.1 Preliminary steps
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the air duct" on page 88
16.6.1.2 Installing the Dual microSD 64GB Enterprise
Figure 389: Position on the system board
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
