RX2540 M4 Upgrade and Maintenance Manual 291
Expansion cards and backup units
9.10.1 Installing a GPGPU card in riser module 1
9.10.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, "Installing the riser card" on page 73
9.10.1.2 Installing a GPGPU card in a riser module
Ê If applicable, remove the slot cover from the riser card holder, see section
"Removing the slot cover" on page 269.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: side cutter
Phillips PH2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
