RX2540 M4 Upgrade and Maintenance Manual 439
14.2.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Locating the defective server" on page 53
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
Ê If applicable, remove the riser module, see section "Riser modules for
GPGPU cards (FL)" on page 82.
14.2.1.2 Removing the front panel cage
Ê Remove the ID card, see figure 408 on page 544.
Figure 318: Disconnecting the front panel cables
Ê Disconnect the following cables from the system board:
1 Front panel cable
2 If applicable, front VGA cable
3 Front USB3.0 cable
If applicable, ODD cable
