282 Upgrade and Maintenance Manual RX2540 M4
Expansion cards and backup units
9.9.1.5 Concluding steps
Ê Install the riser module 1, see section "Installing the riser module 1 (HL)" on
page 75.
Ê "Reassembling" on page 63
Ê Connect all external cables to the expansion card(s).
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Ê If applicable, "Updating expansion card firmware" on page 100.
Ê If applicable, "Enabling Option ROM scan" on page 101.
Ê "Resuming BitLocker functionality" on page 112
9.9.2 Removing an expansion card from riser module 1
9.9.2.1 Preliminary steps
Ê If applicable, "Locating the defective server" on page 53
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê Remove all external cables from the expansion card to be removed.
I If there is a cable installed to an expansion card in the upper slot, see
section "Note for installation with expansion cards in slot 5 and slot
11" on page 71.
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê If applicable, disconnect internal cables from the expansion cards.
Ê If applicable, "Removing an SFP+ transceiver module" on page 244.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
To Next Page
