RX2540 M4 Upgrade and Maintenance Manual 217
Hard disk drives (HDD) and solid state drives (SSD)
7.5.2.2 Removing the rear air grid (left hand)
Figure 130: Removing the rear air grid
Ê Remove three screws (see circles).
Ê Remove the rear air grid.
V CAUTION!
Keep the rear air grid for future use.
Always replace rear air grids into unused installation locations to
comply with applicable EMC regulations and satisfy cooling
requirements.
