392 Upgrade and Maintenance Manual RX2540 M4
Accessible drives
13.1 Basic informations
Mounting order for accessible drives in the front panel cage
The PRIMERGY RX2540 M4 server offers:
– one 5.25-inch accessible drive bays for ODDs
– one bay (optional) for a LTO drive or a RDX drive
I LTO drive or RDX drive are not available for 3.5-inch HDD versions.
Figure 269: Accessible drive in front panel module 3.5-inch HDD version
Figure 270: Accessible drives in front panel module 2.5-inch HDD version
1 ODD 2 RDX drive
LTO drive

Fujitsu PRIMERGY RX2540 M4 Specifications

General

Processor	Intel Xeon Scalable Processor Family
Form Factor	2U rack server
Chipset	Intel C621
Memory	Up to 3TB DDR4
Storage	Up to 24 x 2.5-inch SAS/SATA/NVMe drives or Up to 12 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60 (with optional controller)
Expansion Slots	Up to 8x PCIe Gen3 slots
Power Supply	800W or 1200W (1+1 redundant)
Memory Type	DDR4
Management	iRMC S5 (Integrated Remote Management Controller)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
