RX2540 M4 Upgrade and Maintenance Manual 393
13.2 Optical disk drive (ODD) for the 2.5-inch
version
I For the cable plan, see chapter "Appendix B" on page 573.
13.2.1 Installing the ODD
13.2.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
Ê "Removing the front panel cage" on page 439
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No.1 screw driver
Phillips PZ2 / (+) No.2 screw driver (front panel cage)
