206 Upgrade and Maintenance Manual RX2540 M4
Hard disk drives (HDD) and solid state drives (SSD)
7.4.12 Upgrading the 4x 2.5-inch PCIe SSD backplane
(front side)
7.4.12.1 Preliminary steps
Ê "Locating the defective server" on page 53
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê Remove all HDD/SSD modules from the server, see section "Removing 2.5-
inch HDD/SSD modules" on page 185.
V CAUTION!
Ensure that all HDDs are uniquely identified so that you can reinsert
them into their original bays after replacing the HDD backplane.
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
