Fujitsu PRIMERGY RX2540 M4

RX2540 M4 Upgrade and Maintenance Manual 231
Fans
8.2 Replacing a fan module
8.2.1 Preliminary steps
Ê "Locating the defective server" on page 53
Ê "Getting access to the component" on page 58
Ê "Locating the defective component" on page 54
8.2.2 Removing the fan module
Figure 140: Removing the fan module
Ê Take the fan module by the two handles (1).
Ê Lift the fan module out of the fan holder (2).
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
