Fujitsu PRIMERGY RX2540 M4

RX2540 M4 Upgrade and Maintenance Manual 141
Hard disk drives (HDD) and solid state drives (SSD)
7.2.2 2.5-inch HDD/SSD and 3.5-inch installation frame
I In order to use 2.5-inch HDD/SSD, you can install a 2.5-inch HDD/SSD
in the 3.5-inch installation frame.
Installing a 2.5-inch HDD/SSD in a 3.5-inch installation frame
Figure 49: 2.5-inch HDD/SSD and 3.5-inch installation frame
Ê Lay the 2.5-inch HDD/SSD into the 3.5-inch HDD installation frame as
shown.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
