RX2540 M4 Upgrade and Maintenance Manual 461
14.5.1.1 Preliminary steps
Ê "Locating the defective server" on page 53
Ê "Suspending BitLocker functionality" on page 91
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
14.5.1.2 Removing the front panel on QRL
I The front panel on QRL and the front panel cable are combined in one
spare part.
Figure 338: Disconnecting the front panel cable
Ê Pull up the locking bar (1).
Ê Remove the front panel cable (2).
