RX2540 M4 Upgrade and Maintenance Manual 449
14.3.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 91
Ê "Locating the defective server" on page 53
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
Ê "Removing the fan holder" on page 233
14.3.1.2 Removing the front panel module
Ê Remove the front panel module, see section "Replacing the front panel
module" on page 438.
14.3.1.3 Preparing the front panel module
Figure 330: Removing the front VGA cover plate
Ê Insert a flat screw driver to disengage VGA cover plate from the front panel
cover (1).
Ê Pull the VGA cover plate out of the front panel module.
