RX2540 M4 Upgrade and Maintenance Manual 265
Expansion cards and backup units
Figure 174: Installing a slot cover
Ê Insert a slot cover into the unused PCI slot opening.
Ê Fasten slot cover with the screw (see circle).
9.5.2.4 Concluding steps
Ê "Reassembling" on page 63
Ê "Connecting the power cord" on page 67
Ê "Switching on the server" on page 70
Ê "Resuming BitLocker functionality" on page 112
9.5.3 Replacing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
