Fujitsu PRIMERGY RX2540 M4

494 Upgrade and Maintenance Manual RX2540 M4
Additional interfaces
15.2 Rear VGA connector
15.2.1 Replacing the rear VGA connector
15.2.1.1 Preliminary steps
Ê "Shutting down the server" on page 55
Ê "Disconnecting the power cord" on page 56
Ê "Getting access to the component" on page 58
15.2.1.2 Removing the rear VGA connector
Figure 368: Removing the rear VGA connector (A)
Ê Remove the two hexagon bolts (see circles).
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tool: – hexagon screw driver 5 mm
