Fujitsu PRIMERGY RX2540 M4

424 Upgrade and Maintenance Manual RX2540 M4
Accessible drives
Figure 305: Removing a LTO drive
Ê Remove the screw.
Figure 306: Removing the LTO drive
Ê Unlock the front panel cage, see section "Removing the front panel cage" on
page 439.
Ê Pull out the front panel cage.
