Fujitsu PRIMERGY RX2540 M4

470 Upgrade and Maintenance Manual RX2540 M4
Front panel
Figure 349: Cables on the front panel module
Ê Remove the cable from the desired component.
1 Front panel cable
2 Front USB3.0 cable
3 Location for the optional front VGA connector including the front
VGA board with cable
4 Power ODD cable
5 Data ODD cable
