550 Upgrade and Maintenance Manual RX2540 M4
No. Print Description
1 FP2 Front panel connector (front panel on QRL)
2 USB3.0 INT1 Front USB connector (internal)
3 PWR3 Power connector 3
4 USB3.0 Front Front USB3.0 connector
5 Front VGA Front VGA connector
6 PWR1 Power connector 1
7 PWR2 Power connector 2
8 Front Panel1 Front panel connector
9 FAN1 - FAN6 FAN SYS connectors
10 LC2 Liquid cooling connector CPU2
11 LC1 Liquid cooling connector CPU1
12 PWR ODD ODD power connector
13 OOB FRONT Out-Of-Band HDD status connector
14 VPP CPU1 Connector for PCIe SSD SSF signalling CPU1
15 TPM Connector for Trusted Platform Module (TPM)
16 SATA ODD ODD data connector
17 HDD LED2 LED activity connector 2
18 Intrusion Intrusion switch connector
19 HDD LED1 LED activity connector 1
20 Rear VGA Rear VGA connector
21 SATA 4-7 SATA HDD connector
22 COM 1 Serial interface
23 SATA 0-3 SATA HDD connector
24 VROC
25 Micro SD Slot for micro SD card
26 PWR4 Power connector 4
27 PSU2 Power supply connector hot-plug PSU 2
28 VPP CPU2 Connector for PCIe SSD SSF signalling CPU2
