General-purpose timers (TIM2 to TIM5) RM0090

429/1422 Doc ID 018909 Rev 4

Figure 128. Counter timing diagram, internal clock divided by 1

Figure 129. Counter timing diagram, internal clock divided by 2

Figure 130. Counter timing diagram, internal clock divided by 4

CK_INT

CNT_EN

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

Counter underflow (cnt_udf)

Update event (UEV)

35 34 33 32 31 30 2F04 03 02 01 0005

CK_INT

0001 0036 0035 0034 0033

CNT_EN

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

0002

0000

Counter underflow

Update event (UEV)

0036 0035

CNT_EN

Timer clock = CK_CNT

Counter register

Update interrupt flag (UIF)

0001

0000

Counter underflow

Update event (UEV)

CK_INT
