Window watchdog (WWDG) RM0090

547/1422 Doc ID 018909 Rev 4

19.6.4 WWDG register map

The following table gives the WWDG register map and reset values.

Refer to Table 2 on page 52for the register boundary addresses.

Table 88. WWDG register map and reset values

Offset Register

0x00

WWDG_CR

Reserved

WDGA

T[6:0]

Reset value 01111111

0x04

WWDG_CFR

Reserved

EWI

WDGTB1

WDGTB0

W[6:0]

Reset value 0001111111

0x08

WWDG_SR

Reserved

EWIF

Reset value 0
