General-purpose timers (TIM2 to TIM5) RM0090

479/1422 Doc ID 018909 Rev 4

15.4.19 TIM2 option register (TIM2_OR)

Address offset: 0x50

Reset value: 0x0000

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Reserved

ITR1_RMP

Reserved

rw rw

Bits 15:12 Reserved, must be kept at reset value.

Bits 11:10 ITR1_RMP: Internal trigger 1 remap

Set and cleared by software.

00: TIM8_TRGOUT

01: PTP trigger output is connected to TIM2_ITR1

10: OTG FS SOF is connected to the TIM2_ITR1 input

11: OTG HS SOF is connected to the TIM2_ITR1 input

Bits 9:0 Reserved, must be kept at reset value.
