RM0090 Secure digital input/output interface (SDIO)

Doc ID 018909 Rev 4 874/1422

PERFORMANCE_MOVE

This 8-bit field indicates Pm (performance move) and the value can be set by 1 [MB/sec]

steps. If the card does not move used RUs (recording units), Pm should be considered as

infinity. Setting the field to FFh means infinity.

AU_SIZE

This 4-bit field indicates the AU size and the value can be selected in the power of 2 base

from 16 KB.

Table 138. Speed class code field

SPEED_CLASS Value definition

00h Class 0

01h Class 2

02h Class 4

03h Class 6

04h – FFh Reserved

Table 139. Performance move field

PERFORMANCE_MOVE Value definition

00h Not defined

01h 1 [MB/sec]

02h 02h 2 [MB/sec]

--------- ---------

FEh 254 [MB/sec]

FFh Infinity

Table 140. AU_SIZE field

AU_SIZE Value definition

00h Not defined

01h 16 KB

02h 32 KB

03h 64 KB

04h 128 KB

05h 256 KB

06h 512 KB

07h 1 MB

08h 2 MB
