RM0090 System configuration controller (SYSCFG)

Doc ID 018909 Rev 4 212/1422

Refer to Table 2 on page 52 for the register boundary addresses.

Table 34. SYSCFG register map and reset values (STM32F42xxx and STM32F43xxx)

Offset Register

0x00

SYSCFG_MEMRM

Reserved

MEM_MODE

Reset value xx

0x04

SYSCFG_PMC

Reserved

MII_RMII_SEL

Reserved

ADC3DC2

ADC2DC2

ADC1DC2

Reserved

Reset value 0 000

0x08

SYSCFG_EXTICR1

Reserved

EXTI3[3:0] EXTI2[3:0] EXTI1[3:0] EXTI0[3:0]

Reset value 0000000000000000

0x0C

SYSCFG_EXTICR2

Reserved

EXTI7[3:0] EXTI6[3:0] EXTI5[3:0] EXTI4[3:0]

Reset value 0000000000000000

0x10

SYSCFG_EXTICR3

Reserved

EXTI11[3:0] EXTI10[3:0] EXTI9[3:0] EXTI8[3:0]

Reset value 0000000000000000

0x14

SYSCFG_EXTICR4

Reserved

EXTI15[3:0] EXTI14[3:0] EXTI13[3:0] EXTI12[3:0]

Reset value 0000000000000000

0x20

SYSCFG_CMPCR

Reserved

READY

Reserved

CMP_PD

Reset value 00
