RM0090 Window watchdog (WWDG)

Doc ID 018909 Rev 4 544/1422

19.5 Debug mode

When the microcontroller enters debug mode (Cortex™-M4F core halted), the WWDG

counter either continues to work normally or stops, depending on DBG_WWDG_STOP

configuration bit in DBG module. For more details, refer to Section 33.16.2: Debug support

for timers, watchdog, bxCAN and I2C.

Table 87. Timeout values at 30 MHz (f

PCLK1

)

Prescaler WDGTB

Min timeout (µs)

T[5:0] = 0x00

Max timeout (ms)

T[5:0] = 0x3F

1 0 136.53 8.74

2 1 273.07 17.48

4 2 546.13 34.95

8 3 1092.27 69.91
