RM0090 Flexible static memory controller (FSMC)

Doc ID 018909 Rev 4 1348/1422

10 WRAPMOD 0x0

9 WAITPOL to be set according to memory

8 BURSTEN 0x1

7 Reserved 0x1

6 FACCEN Set according to memory support (NOR Flash memory)

5-4 MWID As needed

3-2 MTYP 0x1 or 0x2

1 MUXEN As needed

0 MBKEN 0x1

Table 212. FSMC_BTRx bit fields

Bit No. Bit name Value to set

31:30 Reserved 0x0

29:28 ACCMOD 0x0

27-24 DATLAT Data latency

23-20 CLKDIV

0x0 to get CLK = HCLK (not supported)

0x1 to get CLK = 2 × HCLK

19-16 BUSTURN Time between NEx high to NEx low (BUSTURN HCLK)

15-8 DATAST Don’t care

7-4 ADDHLD Don’t care

3-0 ADDSET Don’t care

Table 211. FSMC_BCRx bit fields (continued)

Bit No. Bit name Value to set
