Reset and clock control for (RCC) RM0090

179/1422 Doc ID 018909 Rev 4

6.3.30 RCC PLLI2S configuration register (RCC_PLLI2SCFGR)

Address offset: 0x84

Reset value: 0x2000 3000

Access: no wait state, word, half-word and byte access.

This register is used to configure the PLLI2S clock outputs according to the formulas:

● f

(VCO clock)

= f

(PLLI2S clock input)

× (PLLI2SN / PLLM)

● f

(PLL I2S clock output)

= f

(VCO clock)

/ PLLI2SR

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Reserv

PLLI2S

Reserved

rw rw rw

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Reserv

PLLI2SN

Reserved

rw rw rw rw rw rw rw rw rw

Bit 31 Reserved, must be kept at reset value.

Bits 30:28 PLLI2SR: PLLI2S division factor for I2S clocks

Set and cleared by software to control the I2S clock frequency. These bits should be written

only if the PLLI2S is disabled. The factor must be chosen in accordance with the prescaler

values inside the I2S peripherals, to reach 0.3% error when using standard crystals and 0%

error with audio crystals. For more information about I2S clock frequency and precision,

refer to Section 27.4.4: Clock generator in the I2S chapter.

Caution: The I2Ss requires a frequency lower than or equal to 192 MHz to work correctly.

I2S clock frequency = VCO frequency / PLLR with 2 ≤ PLLR ≤ 7

000: PLLR = 0, wrong configuration

001: PLLR = 1, wrong configuration

010: PLLR = 2

...

111: PLLR = 7
