Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 2-23
Theory of Operation
■ Tray 2 Size Switch
The Size Switch detects the size of the paper in the tray.
■ Tray 2 End Guide
The paper size is detected at the End Guide position.
N
o
t
e
Refer to “Paper Size Detection” on page 2-56 for detailed information on
paper size switches and paper size.
s6180mfp-045
Size Switch
Size Switch Actuator
Tray End Guide
s6180mfp-044
Legal 13" (SEF)
Executive (SEF)
B5 (SEF)
A5 (SEF)
Letter (SEF)
A4 (SEF)
Legal 14" (SEF)
Tray 2 End Guide
All paper should be loaded SEF.
