2-24 Phaser 6180MFP Multifunction Printer Service Manual
Theory of Operation
â–  Tray 2 No Paper Sensor
The No Paper Sensor detects the presence of the paper in the tray based
on the Tray 2 No Paper Actuator position.
s6180mfp-046
No Paper Sensor
No Paper Actuator
Actuator (No Paper Position)
