Phaser 6180MFP Multifunction Printer Service Manual 2-41
Theory of Operation
Boards
Control Panel
The Control Panel displays the machine status and operates the printer/
scanner/copier/fax.
LVPS
s6180mfp-377
MCU Board
Scanner
Controller Board
Fax Board
IP Board
Multi-Protocol Network Card
s6180mfp-133
Clear All
Error
Power Saver
Stop
Start
001 002
003 004
005 006
007 008
009 010
Copy
Fax
E-mail
Scan
Color Mode
B&W
Color
OK
Job in Memory
Job Status
ABC
GHI
PQRS
Redial/
Pause
Speed Dial
-_~
TUV WXYZ
JKL MNO
@:./
123
4
56
7
8
0
C
#
9
DEF
System
Manual Dial

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
