Xerox Phaser 6180MFP Service Manual

2-68 Phaser 6180MFP Multifunction Printer Service Manual
Theory of Operation
Front View
s6180mfp-068
[Full Color Mode]
Main Motor
Drive Gear
[Belt]
Drum Gear (K)
[Drum (K)]
Drum Gear (C)
[Drum (C)]
Drum Gear (M)
[Drum (M)]
Drum Gear (Y)
[Drum (Y)]
Developer
Motor
Front
[Name of Moving Parts]
Magnet Roller Gear (K)
[Magnet Roller (K)]
Developer Idler Gear (K)
Auger Gear (K)
[Supply Auger (K)]
Auger Gear (K)
[Admix Auger (K)]
Magnet Roller Gear (C)
[Magnet Roller (C)]
Developer Idler
Gear (C)
Auger Gear (C)
[Supply Auger (C)]
Auger Gear (C)
[Admix Auger (C)]
Magnet Roller Gear (M)
[Magnet Roller (M)]
Developer Idler Gear (M)
Auger Gear (M)
[Admix Auger (M)]
Auger Gear (M)
[Supply Auger (M)]
Magnet Roller Gear (Y)
[Magnet Roller (Y)]
Developer Idler Gear (Y)
Auger Gear(Y)
[Admix Auger (Y)]
Auger Gear (Y)
[Supply Auger (Y)]
Sub Motor

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
