Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-25
Error Messages and Codes
4 1.Replace the paper.
2.Does the error still occur?
Replace the Tray
2 Retard Roller
(page 8-15).
Complete.
5 1.Replace the Feed Roller (page 8-14).
2.Does the error still occur?
Go to step 6. Complete.
6 1.Check the paper?
2.Does the error still occur?
Replace the
Feeder Unit
(page 8-47).
Complete.
7 1.Check the wiring harness
connectors P/J23, P/J232, and P/
J2322 between the MCU Board and
the Registration Sensor.
2.Are the connectors securely
connected?
Go to step 8. Reconnect the
connectors.
8 Check the Registration Sensor
Harness for continuity.
1.Disconnect P/J2322 from the
Registration Sensor.
2.Disconnect P/J232 from the Right
Side Harness.
3.Check continuity between P/J232
<=> P/J2322.
Go to step 9. Replace the
Registration
Sensor
Harness.
9 Check the Right Side Harness for
continuity.
1.Disconnect P/J23 from the MCU
Board.
2.Disconnect P/J232 from the
Registration Sensor Harness.
3.Check continuity between P/J23 <=>
P/J232.
Go to step 10. Replace the
Right Side
Harness.
10 Check the Registration Sensor signal.
1.Disconnect P/J23 from the MCU
Board.
2.Is there +3.3 V across ground <=>
J23-8 pin on the MCU Board?
Replace the
MCU Board
(page 8-88).
Replace the
Registration
Sensor
(page 8-44).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
